Automatic Filling cum Sealing Machine
Automatic AUGER TYPE LINEAR AND ROTARY POWEDR Filling cum Sealing Machine – Monoblock Type
| MODEL | NPALRPFM – 40 |
|---|---|
| OUTPUT | 25 – 30 [DEPENDING ON MATERIAL ] |
| HOPPER CAPACITY | 25 LTR |
| ACCURACY | ± 1 % |
| POWER | 220 / 440 V , 50HZ [ FOUR WIRE ] |
| ELECTRIC MOTOR | 1.5HP, 220 / 415 V, 50 HZ [FOUR WIRE] |
| CONVEYOR HEIGHT | 850 MM TO 950 MM ADJUSTABLE |
| BOTTLE SIZE | Ø 22 MM TO Ø 100 MM , MAXIMUM HEIGHT 210 MM |
| CAP SIZE | 22 MM TO 80 MM MAXIMUM, WITH THE HELP OF CHANGE PART OVERALL DIMENSION |
| IN [MM] APPROX | 2133 [L] X 1070 [W] X 1828 [H] |
| NET WEIGHT [KG] APPROX | 500 |
